Featured Products:

HTG-ADC16 / HTG-DAC16
Quad Channel 16-bit ADC/DAC FMC
Module

Vita 57.4 (FMC+)
Quad Channel 16-bit ADC and Quad/Dual Channel 16-bit DAC Serial FMC Module

More info..

HTG-K800
Xilinx Kintex UltraScale PCI Express Platform

8-lane Gen3 PCI Express platform with two FMC HPC expansion connectors (total  of 20 GTH transceivers and 320 single-ended I/Os) , DDR4 (2.5GB), high-speed Z-Ray GTH gigabit port (16x16G), UART/USB, 1Gb embedded flash and XADC headers

More info..

HTG-9100
Xilinx Virtex UltraScale 900Gig Optical Networking Platform

Optical Networking platform with four CFP4 (4x100G), five QSFP28 (5x100G), FMC+ (24 GTH transceivers and160 single-ended I/Os), SMA ports (4x16G), DDR4 components (5GB) and one Samtec FireFly port (12x16G)

More info..

HTG-828
Xilinx Virtex UltraScale 100G NIC

100GIG Networking platform with 16-Lane Gen3 PCI Express, two CFP4 (2x100G), one QSFP28 (1x100G),  Cypress QDR IV (144Mb), DDR4 (5GB), Mini SMP (8x30G), high-speed Z-Ray GTY gigabit port (16x30G), FMC+ (Vita57.4) with 24 GTH (16G) transceivers and 160 single-ended I/Os.

More info..

HTG-K816
Xilinx Kintex UltraScale Half-Size PCI Express Platform

Half-size (6.6"x2.5") Gen3 PCI Express platform with one high-speed Z-Ray GTH gigabit port (16x16G), DDR4 (5GB), board-to-board connectors (LVDS & serial) , GPS, and supported by QSFP+, SFP+, Hybrid Memory Cube (HMC) Modules

More info..

HTG-830
Xilinx Virtex / Kintex UltraScale
 Development Platform

8-lane Gen3 PCI Express platform with two Vita57.4 FMC+ connectors (total of 320 single-ended I/Os, 20 GTY, and 22 GTH transceivers), one vita57.1 FMC connector (24 single-ended I/Os and 10 GTH transceivers), high-speed     Z-Ray GTY gigabit port (16x30G), and  one DDR4 SODIMM socket (up to 16GB)


More info..
