CPU
|
Intel® Socket 1366 Core™ i7 Processor
Extreme Edition/Core™ i7 Processor Supports
Intel® Dynamic Speed Technology
* Refer to www.asus.com for Intel CPU support list
|
|
Chipset
|
Intel® X58 /ICH10R
|
|
System Bus
|
Up to 6400 MT/s with QuickPath
Interconnection
|
|
Memory
|
6 x DIMM, Max. 24 GB, DDR3
2000(O.C.)/1800(O.C.)/1600(O.C.)/1333/1066 Non-ECC,Un-buffered
MemoryTriple channel memory architecture
* Supports Intel® Extreme Memory Profile (XMP)
|
|
Expansion Slots
|
2 x PCIe 2.0 x16 support at dual x16
speed
1 x PCIe 2.0 x4
1 x PCI 2.2
|
|
Multi-GPU Support
|
Support NVIDIA SLI™ / ATI CrossFireX™
Technology
|
|
Storage
|
Intel ICH10R controller
6 x SATA 3 Gb/s ports
Intel Matrix Storage Technology Support RAID
0,1,5,10
JMicron® JMB363 PATA and SATA controller
1 x UltraDMA 133/100/66/33 for up to 2 PATA devices
1 x Internal SATA 3.0 Gb/s port
1 x External SATA 3.0 Gb/s port (SATA On-the-Go)
|
|
LAN
|
Realtek® 8111C PCIe Gigabit LAN
controller featuring AI NET2
|
|
Audio
|
SupremeFX X-Fi built-in 8 -Channel
High Definition Audio CODEC
EAX® Advanced™ HD 4.0
X-Fi CMSS®-3D
X-Fi Crystalizer™
Creative ALchemy
Supports Optical S/PDIF out ports on rear
|
|
IEEE 1394
|
2 x 1394a ports (1 port at back I/O,
1 port onboard)
|
|
USB
|
12 xUSB 2.0 ports (6 ports at
mid-board, 6 ports at back panel)
|
|
ASUS Unique Features
|
Power Design
- 8-phase CPU power
- 2-phase QPI/DRAM power
- 2-phase NB power
- 2-phase Memory power
CPU Level Up
Keyboard-TweakIt
Memory Level Up
iROG
Extreme Tweaker
Loadline Calibration
Intelligent overclocking tools:
- ASUS AI Booster Utility
- O.C. Profile
Overclocking Protection:
- COP EX (Component Overheat Protection - EX)
- Voltiminder LED
- ASUS C.P.R.(CPU Parameter Recall)
|
|
Special Features
|
MemOK!
External LCD Poster
Q-Fan Plus
ASUS EPU-6 Engine
ASUS Q-Connector
ASUS Fan Xpert
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
ASUS MyLogo3
|
|
Back Panel I/O Ports
|
1 x External SATA
1 x IEEE 1394a
1 x LAN(RJ45) port
6 x USB 2.0/1.1
8 -Channel Audio I/O
1 x PS/2 Keyboard port(purple)
1 x S/PDIF (Optical)
1 x Clr CMOS switch
|
|
Internal I/O Connectors
|
3 x USB connectors supports
additional 6 USB 2.0 ports
1 x IDE connector for two devices
7 x SATA connectors
5 x Fan connectors: 1 x CPU / 2 x Chassis / 2 x
Optional
2 x thermal sensor connectors
1 x IEEE1394a connector
1 x LCD Poster connector
1 x Chassis Intrusion connector
24-pin ATX Power connector
8-pin ATX 12V Power connector
1 x En/Dis-able Clr CMOS header
1 x Front panel audio connector
1 x CD audio in
System panel connector
|
|
BIOS
|
16 Mb Flash ROM
AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.4, ACPI2.0a
Multi-Language BIOS
|
